Culture Media Preparators

Ultrassay Culture media preparators feature an advanced sterilization system that includes: heating, sterilization and fast cooling. This process not only ensures the effective elimination of all microorganisms, but also drastically boosts the laboratory’s time management and productivity.

Inquire

Brochure Download

Main Features

Professional reproducibility: By performing a single weighing and processing the entire preparation under identical conditions, much better precision and reproducibility are achieved.
Perfect homogeneity: Achieves even mixing of all elements in the medium by leveraging the built-in continuous stirring system of the equipment. This system allows for speed adjustment to suit a range of demands.
Accurate control of temperature: A PT-100 flexible temperature probe continuously measures the medium’s temperature, enabling the microprocessor to regulate the cycle based on temperature or directly through lethality using the F0 value.
Time savings: The integration of multiple functions into a single device, along with the fast cooling system, allows for increased productivity and optimized workflow.
Advanced safety: Our designs prioritize user safety and comfort, incorporating features such as automatic door locking, thermally insulated covers, casters for ease of transportation and alarm systems that notify of malfunctions or cycle completion alerts.
Reduction of human error: By greatly reducing the need for human intervention, we eliminate the usual errors associated with manual operations like imprecise measurements, omitted steps, and operator technique discrepancies.

Technical Specification

Model	MediaPrep-12/23	MediaPrep-45/60	MediaPrep-70/90
Capacity	12L / 23L	45L / 60L	70L / 90L
Chamber Size (Ø×H)	316×300 mm	400×500 mm	400×720 mm
Bucket size (Ø×H)	250×250 mm	380×400 mm	380×620 mm
Design temperature	150 °C
Max. Temperature	140 °C
Sterilization temperature	105~136 °C
Dispensing temperature	40~100 °C
Water bath temperature	40~60 °C
Temperature accuracy	0.1 °C
Sterilization Time	0~999 mins
Max. allow pressure	3 bar
Design pressure	0~4 bar
Chamber feeding water	Deionized water, pressure ≥ 1bar, with high and low liquid level alarm
Circulating water	Tap water, pressure ≥ 1bar
Chamber material	SUS316L
Dispensing port	1	2
Feeding port	1	1	1
Stirrer speed	120, 240rpm quick selectable; 0~240rpm stepless adjustable
Power consumption	6 KW	12 KW
Power supply	220V/50Hz	380V/50Hz
Dimensions (W×D×H)	550×700×550 mm	750×800×880 mm	750×800×880 mm
Weight	80 KG	122 KG	160 KG
Safety device	Overtemperature automatic protection device, Dry burn protection device, Door safety interlock device, Overpressure automatic relief safety valve
Peristaltic Pump
Max. dispensing volume	1ml ~ 10L
Flow rate	0.6ml~7000 ml/min
Dispensing error	≤ ±0.5%
