Ultrassay® BSC-654IIA2 Desktop Biosafety Cabinet is a vertical laminar flow cabinet with 70% circulation, 30% exhaust, mini desktop type, That specially designed for PCR experiments in a small laboratory.
Features
- Small and portable design, placed on the table, suitable for relatively small space.
- The newly designed sliding door lifting and positioning system can be used safely under severe conditions.
- The fan and sliding door linkage design, when the sliding door reaches the working height, the fan can be automatically started.
- DC fan intelligent constant air volume compensation system, when the HEPA filter resistance increases by 50%, the inflow air volume change is less than 10%, ensuring safer operation.
Basic Characteristics
- Humanizes structure: 10°sloped front design, demountable circular-arc armrest, working area is made of stainless steel fully finished, equipped with anti-splash safety socket.
- Safe and reliable: The sliding door is interlocked with the lighting and sterilization system. The self-made high-efficiency filter using imported filter material has large dust holding capacity and good uniformity. Adopt negative pressure to surround the double-layer box structure, “leakage resistance” and “unobstructed return air” technology, Through strict cabinet leak prevention testing, high efficiency filter integrity testing, etc.
- Function control: It adopts graphic man-machine dialogue interface and touch button controller. The full-color LCD screen displays parameters such as downflow air velocity, inflow air velocity, filter service life and clogging alarm, fan operation status and fault alarm, real-time monitoring and display of BSC running time and other parameters.
Structure
Technical Specification
| Model | BSC-654IIA2 |
| Nominal Size | 0.65 meter (2’’) |
| Filtration Efficiency | ≥ 99.995%, @0.3μm |
| Downflow Velocity | 0.33 m/s |
| Inflow Velocity | 0.55 m/s |
| Noise | ≤63 dB (A) |
| Vibration | ≤5 μm (Center of table top) |
| Power Supply | AC 220~240V, 50/60Hz |
| Opening Height | 200 mm |
| Personnel Protection | A. Total colony in impaction sampler≤10CFU./time |
| B. Total colony in slot sampler≤5CFU./time | |
| Product Protection | Total colony in culture dish≤5CFU./time |
| Cross-contamination Protection | Total colony in culture dish≤2CFU./time |
| Max Consumption (with spare socket) | 0.81 KVA |
| Rated Power (without spare socket) | 0.15 KVA |
| Weight | 110 Kg |
| Working Dimension | W650 x D562 x H540mm |
| Overall Dimension | W750 x D700 x H1200mm |
| Light Source | LED 13W x 1 |
| Sterilization | UV light 8W x 1 |
| Illumination | >=900 Lx |
| Cabinet Material | High-grade steel and lacquered in ivory |
| Working Area Material | SUS304 fully finished |
| Air Direction | Top out |
